Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister

I'm Online Chat Now

Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister

Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister
Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister

Large Image :  Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister

Product Details:
Place of Origin: Hengshui, China
Brand Name: Hualai
Certification: ISO9001-2015
Model Number: HL-Ti
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negociation
Packaging Details: Wooden box
Delivery Time: 5-8 days
Payment Terms: L/C, T/T
Supply Ability: 999 pcs per month

Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister

Description
Material: Titanium Wire Size: Almost Any Size As Ordered
Feature: Anti Corrosive Use: Gas Liquid Separator
Sections: According To Man Way Color: Black
High Light:

mesh pad demister

,

wire mesh pad

Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister





1. Titanium Anti Corrosive Metal Mesh Wire Mesh Demister



Demister pads or Mist eliminators are porous blankets of metal or plastic knitted wire mesh, designed and constructed for the efficient, economical removal of entrained liquid droplets from vapor streams. Demister Pads can be fabricated in any required size and shape and may be installed in new or existing process vessels.



2. How Titanium Anti Corrosive Metal Mesh Wire Mesh Demister Works?



When vapor and entrained liquid droplets pass through a mist eliminator, the vapor moves freely through the mesh pad but the liquid droplets, due to their greater inertia, cannot make the necessary sharp turns and as a result are thrown into contact with the wire surfaces and briefly held there. As more droplets enter the pad and collect on the wires, they grow in size, run down the wire to the bottom surface of the mesh separator and fall from the unit. Overhead vapor is now free of entrained liquid.



3. Titanium Anti Corrosive Metal Mesh Wire Mesh Demister's specifications:



Item Value Unit
Material Titanium /
Shape & Size Φ750 mm
Mesh Thickness 100 mm
Demsiter Height 150 mm
Wire Diameter 0.25 mm
Mesh Density 81 kg/m3
Void Fraction 0.982 /
Specific Area 287 m2/m3
Grids 25*3 flat bar mm



4. Titanium Anti Corrosive Metal Mesh Wire Mesh Demister Advantages:

1. Simple installation;

2. Low pressure loss;

3. 90% to 99.9% efficiency;

4. Little maintenance is required;

5. Elimination of liquid product loss;

6. Essential improvement of vapor phase quality;

7. Dimensions and configurations are not limited;

8. Contacting surface area is larger than the specific gravity;

9. Compact equipment can be used in accordance with increased production capacity;

10. No direct power is required since the equipment has no operating parts


5. Titanium Anti Corrosive Metal Mesh Wire Mesh Demister Aplications:



  • Reduce loss of valuable chemicals: demister pads markedly cut glycol, amine, or solvent consumption in absorption and regeneration towers.
  • Increase throughput capacity: demister pads allow a significant increase in throughput anywhere gases and liquids come into contact in process equipment.
  • Improve product purity: demister pads prevent contamination of side draws and overheads in refinery atmospheric and vacuum towers and other distillation columns.
  • Minimize contamination: demister pads can prevent the poisoning of expensive downstream catalysts or provide boiler feed water quality condensate from evaporator overheads.
  • Provide equipment protection: demister pads protect turbine, blower, and compressor blades, which can eliminate serious maintenance problems.
  • Reduce air pollution: demister pads help diminish droplet emissions to environmentally acceptable levels.



6. Hualai demister package & shipping:


Titanium Anti Corrosive Metal Mesh Mist Eliminator Wire Mesh Demister 0
Welcome your inquiry with any questions! Here in Hualai we are always ready to be helpful!
